Specification
- Battery 48V 20Ah Samsung/LG lithium battery
- Range 60–80 miles
- Hub Motor 750W brushless geared hub motor
- Total Payload Capacity 400 lb.
- Recommended Rider Heights 5′4″ ~ 6′4″
- Charger US standard 3.0 A smart charger
- Controller 48V/22A
- Display LCD display with USB charging
- Weight 88 lb.
- Pedal Assist Intelligent 0~5 level pedal assist
Components
-
- Tires 26″ x 4.8″ CST fat tires
- Rear Light Battery-powered bike light
-
Freewheel Shimano 7 speed gear shift system
- Brake Tektro 180mm hydraulic brakes
- Chain KMC chain
- Stem MA-400 28.6*90*31.8MM
- Crank 44T*170MM 4-jaw L/R forged alloy
- Gearing Shimano- 14-28T BROWN/BK
- Front Fork Alloy front suspension fork with lockout and adjustment
- Throttle Thumb throttle
- Pedal Alloy pedal with reflectors
- Bike Frame 6061 Aluminum frame
- Front Light 48V LED light
- Saddle SR saddle
- Seat Post 30.9*350mm Alloy Seatpost
- Kickstand Heavy-duty aluminum
- Spokes 13 Gauge on the front wheel/ 12 Gauge on the rear wheel
Geometry
A -- Total Length 82.6
- B -- Handlebar Height 42.9
- C -- Wheelbase 51.1
- D -- Minimum Seat Height 30.3
- E -- Maximum Seat Height 37
- F -- Chain Stay Length 19.7
- G -- Standover Height 32
- H -- Top Tube Length 24
- I -- Wheel Diameter 30.3
- J -- Head Tube Length 5.1
- K -- Handlebar Length 27.6
